| PART |
Description |
Maker |
| 5219-RC 5220-RC 5250-RC |
High I , Radial Choke 1 ELEMENT, 4.9 uH, IRON-CORE, GENERAL PURPOSE INDUCTOR
5200 Series - Hash Choke
|
Bourns, Inc.
Bourns Electronic Solut...
|
| 8044 |
CHOKE Surface Mount Common Mode Choke
|
FILTRAN[Filtran LTD]
|
| 8041 |
CHOKE SURFACE MOUNT COMMON MODE CHOKE
|
Filtran LTD
|
| ATH15 ATH12 ATH06 ATH06T033 |
CHOKE,AXIAL,CONFORMAL,0.68uH, 10% INDUCTIVE TOL,495 IDC,
CHOKE,AXIAL,CONFORMAL,8.2uH, 5% INDUCTIVE TOL,155 IDC,
CHOKE,AXIAL,CONFORMAL,47uH, 10% INDUCTIVE TOL,167 IDC,
CHOKE,AXIAL,CONFORMAL,470uH, 5% INDUCTIVE TOL,53 IDC,
|
Astec America, Inc
|
| DLP31DN131ML4L DLP31DN321ML4L DLP31DN201ML4L DLP31 |
CHOKE COM MODE ARRY 130 OHM 1206 4 FUNCTIONS, 10 V, 0.12 A, DATA LINE FILTER
CHOKE COM MODE ARRY 320 OHM 1206 4 FUNCTIONS, 10 V, 0.08 A, DATA LINE FILTER
CHOKE COM MODE ARRY 200 OHM 1206 4 FUNCTIONS, 10 V, 0.1 A, DATA LINE FILTER
CHOKE COM MODE ARRY 440 OHM 1206 4 FUNCTIONS, 10 V, 0.07 A, DATA LINE FILTER
EMI COMMON MODE CHOKE 1206 90OHM@100MHZ
|
Murata Manufacturing Co., Ltd.
MURATA MANUFACTURING CO LTD
|
| U2009-150Y U2009-220Y U2009-3R3Y U2009-4R4Y |
CHOKE, POWER, SHIELDED, 15UH; Inductor type:Shielded Power Choke; Inductance:15uH; Tolerance, inductance:30%; Resistance:1370mR; Frequency, resonant:40MHz; Case style:SMD Shielded; Q factor:10; Material, core:Ferrite DR/RI; RoHS Compliant: Yes
CHOKE, POWER, SHIELDED, 22UH; Inductor type:Shielded Power Choke; Inductance:22uH; Tolerance, inductance: /-30%; Resistance:2600mR; Frequency, resonant:30MHz; Case style:SMD Shielded; Q factor:10; Material, core:Ferrite DR/RI; RoHS Compliant: Yes
CHOKE, POWER, SHIELDED, 3.3UH; Inductor type:Shielded Power Choke; Inductance:3.3uH; Tolerance, inductance: /-30%; Resistance:320mR; Frequency, resonant:100MHz; Case style:SMD Shielded; Q factor:7; Material, core:Ferrite DR/RI; RoHS Compliant: Yes
CHOKE, POWER, SHIELDED, 4.4UH; Inductor type:Shielded Power Choke; Inductance:4.4uH; Tolerance, inductance: /-30%; Resistance:430mR; Frequency, resonant:85MHz; Case style:SMD Shielded; Q factor:7; Material, core:Ferrite DR/RI; RoHS Compliant: Yes
|
BOURNS INC
|
| ELC09D2R2F ELC09D100F ELC09D102F ELC09D2R3F ELC09D |
SPECIFICATION CHOKE COIL
This specification covers the CHOKE COIL
|
List of Unclassifed Manufacturers
|
| 1120-222K-RC 1120-1R2M-RC 1120-680K-RC 1120-681K-R |
RF Choke; Series:1120; Inductance:2.2mH; Inductance Tolerance: /- 10 %; Terminal Type:Radial Leaded; Core Material:Ferrite; Current Rating:800mA; DC Resistance Max:1.54ohm; Leaded Process Compatible:Yes; Body Material:Ferrite
RF Choke; Series:1120; Inductance:1.2uH; Inductance Tolerance: /- 20 %; Terminal Type:Radial Leaded; Core Material:Ferrite; Current Rating:11.4A; DC Resistance Max:0.003ohm; Leaded Process Compatible:Yes; Body Material:Ferrite
RF Choke; Series:1120; Inductance:68uH; Inductance Tolerance: /- 10 %; Terminal Type:Radial Leaded; Core Material:Ferrite; Current Rating:4.8A; DC Resistance Max:0.053ohm; Leaded Process Compatible:Yes; Body Material:Ferrite
RF Choke; Series:1120; Inductance:680uH; Inductance Tolerance: /- 10 %; Terminal Type:Radial Leaded; Core Material:Ferrite; Current Rating:1.6A; DC Resistance Max:0.430ohm; Leaded Process Compatible:Yes; Body Material:Ferrite
RF Choke; Series:1120; Inductance:1.8uH; Inductance Tolerance: /- 20 %; Terminal Type:Radial Leaded; Core Material:Ferrite; Current Rating:11.4A; DC Resistance Max:0.003ohm; Leaded Process Compatible:Yes; Body Material:Ferrite
RF Choke; Series:1120; Inductance:330uH; Inductance Tolerance: /- 10 %; Terminal Type:Radial Leaded; Core Material:Ferrite; Current Rating:1.6A; DC Resistance Max:0.305ohm; Leaded Process Compatible:Yes; Body Material:Ferrite
RF Choke; Series:1120; Inductance:470uH; Inductance Tolerance: /- 10 %; Terminal Type:Radial Leaded; Core Material:Ferrite; Current Rating:1.6A; DC Resistance Max:0.355ohm; Leaded Process Compatible:Yes; Body Material:Ferrite
RF Choke; Series:1120; Inductance:1.5mH; Inductance Tolerance: /- 10 %; Terminal Type:Radial Leaded; Core Material:Ferrite; Current Rating:800mA; DC Resistance Max:1.26ohm; Leaded Process Compatible:Yes; Body Material:Ferrite
Very high current capacity
|
BOURNS INC
Bourns Electronic Solut...
|
| EB0057-DL |
PFC Choke
|
Coilcraft lnc.
|
| 744777928 |
POWER-CHOKE WE-PD
|
Wurth Elektronik GmbH &...
|
|
