| PART |
Description |
Maker |
| TO-263-5 |
A : MIN 9.800 MAX 10.668 B : MIN 8.200 MAX 9.169
|
Analog Microelectronics
|
| 2PA1774Q115 |
PNP general-purpose transistor - Complement: 2PC4617Q ; fT min: 100 MHz; hFE max: 270 ; hFE min: 120 ; I<sub>C</sub> max: 100 mA; Polarity: PNP ; Ptot max: 150 mW; VCEO max: 40 V; Package: SOT416 (SC-75); Container: Tape reel smd
|
NXP SEMICONDUCTORS
|
| PMBT5550 PMBT5550_3 PMBT5550215 |
NPN high-voltage transistor - Complement: PMBT5401 ; fT min: 100 MHz; hFE max: 250 ; hFE min: 60 ; I<sub>C</sub> max: 300 mA; Polarity: NPN ; Ptot max: 250 mW; VCEO max: 140 V; Package: SOT23 (TO-236AB); Container: Tape reel smd
From old datasheet system
|
NXP SEMICONDUCTORS
PHILIPS[Philips Semiconductors]
|
| PRGA24150 PRGD2415010 PRGD48150 PRGD60150 PRGA6015 |
Solid-State Panel Mount Relay; Output Device:SCR; Output Voltage Max:280Vrms; Output Voltage Min:24Vrms; Control Voltage Max:140VAC; Control Voltage Min:90VAC; Load Current Max:150A; Switching:Zero Cross
|
CRYDOM CORP
Crydom Inc.,
|
| PMBTA92 PMBTA92215 PMBTA92-T |
100 mA, 300 V, PNP, Si, SMALL SIGNAL TRANSISTOR, TO-236AB
PNP high-voltage transistor - Complement: PMBTA42 ; fT min: 50 MHz; hFE max:>40 ; hFE min: 40 ; I<sub>C</sub> max: 100 mA; Polarity: PNP ; Ptot max: 250 mW; VCEO max: 300 V; Package: SOT23 (TO-236AB); Container: Tape reel smd
|
NXP Semiconductors
|
| DPA4111 |
Solid-State PC Board Relay; Output Device:SCR; Output Voltage Min:20Vrms; Output Voltage Max:140Vrms; Load Current Max:1A; Switching:Zero Cross; Output Current Max:1A; Output Current Min:0.025Arms; Output Type:SCR RoHS Compliant: Yes
|
CRYDOM CORP
|
| SC-70-6 |
A : MIN 0.80 MAX 1.10 A1 : MIN 0.00 MAX .010
|
Analog Microelectronics
|
| MP120D2 MP240D2 MPDCD3-B |
; Output Device:Transistor; Output Voltage Max:60VDC; Output Voltage Min:3VDC; Control Voltage Max:32VDC; Control Voltage Min:3VDC; Load Current Max:3A; Switching:Zero Cross; Leaded Process Compatible:Yes; Output Current Max:3A
|
Crydom Inc.
CRYDOM CORP
|
| E28 E116 E113 E30 E106 E103 E105 E112 E209 E3 E100 |
Yellow, mini LED. Lens translucent. Luminous intensity at 10mA: 2.0mcd(min), 3.5mcd(max). Forward voltage at 20mA: 2.1V(typ), 2.5V(max).
Orange InGaAIP, T-1 3/4, ultra bright LED. Lens orange translucent. Luminous intensity at 20mA: 700mcd(min), 3000mcd(max). Forward voltage at 20mA: 1.8V(typ), 2.3V(max).
Super bright green, mini LED. Lens translucent. Luminous intensity at 10mA: 10.0mcd(min), 16.0mcd(max). Forward voltage at 20mA: 2.2V(typ), 2.5V(max).
Green T-1, right angle LED(3mm). Lens diffused. Luminous intensity at 10mA: 5.0mcd(typ), 20.0mcd(max). Forward voltage at 20mA: 2.2V(typ), 2.5V(max).
Red T-1, right angle LED(3mm). Lens diffused. Luminous intensity at 10mA: 12.5mcd(typ), 32.0mcd(max). Forward voltage at 20mA: 2.0V(typ), 2.5V(max).
T-1 bright white LED / Lens clear
Miniature LEDs 微型发光二极
Orange, mini LED. Lens translucent. Luminous intensity at 10mA: 3.0mcd(min), 7.0mcd(max). Forward voltage at 20mA: 2.0V(typ), 2.6V(max).
Yellow T-1, right angle LED(3mm). Lens diffused. Luminous intensity at 10mA: 5.0mcd(typ), 20.0mcd(max). Forward voltage at 20mA: 2.1V(typ), 2.5V(max).
High efficiency red, mini LED. Lens translucent. Luminous intensity at 10mA: 4.0mcd(min), 7.0mcd(max). Forward voltage at 20mA: 2.0V(typ), 2.5V(max)(max).
Ultra bright red, mini LED. Lens translucent. Luminous intensity at 10mA: 20.0mcd(min), 60.0mcd(max). Forward voltage at 20mA: 1.85V(typ), 2.5V(max)(max).
Yellow InGaAIP, T-1 3/4, ultra bright LED. Lens yellow translucent. Luminous intensity at 20mA: 400mcd(min), 1600mcd(max). Forward voltage at 20mA: 2.0V(typ), 2.5V(max).
|
Gilway Technical Lamp
International Light Technologies Inc.
International Light Technologies, Inc.
|
| H11G1SR2M H11G1SR2VM H11G1TM H11G1TVM H11G2M H11G1 |
Zener Diode; Application: General; Pd (mW): 400; Vz (V): 3.8 to 4.0; Condition Iz at Vz (mA): 5; C (pF) max: -; Condition VR at C (V): ESD (kV) min: -; Package: MHD
Zener Diode; Application: General; Pd (mW): 400; Vz (V): 3.9 to 4.1; Condition Iz at Vz (mA): 5; C (pF) max: -; Condition VR at C (V): ESD (kV) min: -; Package: MHD
Zener Diode; Application: General; Pd (mW): 400; Vz (V): 4.1 to 4.3; Condition Iz at Vz (mA): 5; C (pF) max: -; Condition VR at C (V): ESD (kV) min: -; Package: MHD
Zener Diode; Application: General; Pd (mW): 400; Vz (V): 4.2 to 4.4; Condition Iz at Vz (mA): 5; C (pF) max: -; Condition VR at C (V): ESD (kV) min: -; Package: MHD
Zener Diode; Application: General; Pd (mW): 400; Vz (V): 4.4 to 4.6; Condition Iz at Vz (mA): 5; C (pF) max: -; Condition VR at C (V): ESD (kV) min: -; Package: MHD
Zener Diode; Application: General; Pd (mW): 400; Vz (V): 4.0 to 4.2; Condition Iz at Vz (mA): 5; C (pF) max: -; Condition VR at C (V):   ESD (kV) min: -; Package: MHD 1 CHANNEL DARLINGTON OUTPUT OPTOCOUPLER
|
Fairchild Semiconductor Corporation
Fairchild Semiconductor, Corp.
|
| FK20UM-5 |
Bench Power Supply; Output Voltage:16V; Output Current:10A; Number of Outputs:1; Calibrated:No; Display Technology:LED; Output Current Max:10A; Output Current Min:0A; Output Voltage Max:16V; Output Voltage Min:0V
Nch POWER MOSFET HIGH-SPEED SWITCHING USE
|
POWEREX[Powerex Power Semiconductors]
|
| SOP-16 |
A : MIN 1.35 MAX 1.75 A1 : MIN 0.10 MAX 0.25
|
Analog Microelectronics
|
